| 型号 |
|
JK8476 | JK8477 |
| 额定载重 | kg | 1000 | 1000 |
| 载荷中心(C) | mm | 585 | |
| 货叉最高高度(H) | mm | 1500 | 2500 |
| 货叉最低高度(h) | mm | 88 | |
| 货叉长度(L) | mm | 1150 | |
| 单个货叉宽度(D) | mm | 160 | |
| 货叉整体宽度(W) | mm | 540 | |
| 离地间距(X) | mm | 42 | |
| 最小转弯半径 | mm | 1355 | 1355 |
| 载轮(前轮) | mm | Φ80×70 | |
| 驱动轮(后轮) | mm | Φ150×50 | Φ150×50 |
| 整车长度(A) | mm | 1604 | |
| 整车宽度(B) | mm | 760 | 760 |
| 整车高度(F) | mm | 1964 | |
| 净重 | kg | 220 | 330 |
